HP HPE Aruba Networking Aruba 6200F 24G Class4 PoE 4SFP+ 370W Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U

Design
Rack mounting: Yes
Form factor: 1U
Stackable: Yes
Airflow direction: Fronttoback airflow

Power
Power supply included: Yes
AC input voltage: 100 240 V
Number of power supply units: 1
Power source: AC
AC input frequency: 50/60 Hz

Security
IGMP snooping: Yes
DHCP features: DHCP relay, DHCP server
Access Control List (ACL): Yes
Authentication: MACbased authentication, Webbased authentication
Authentication type: RADIUS, TACACS+

Operational conditions
Operating altitude: 0 3048 m
Operating temperature (TT): 0 45 C
Nonoperating altitude: 0 4600 m
Storage temperature (TT): 40 70 C
Storage relative humidity (HH): 15 90%
Operating relative humidity (HH): 15 95%

Management features
Switch type: Managed
Quality of Service (QoS) support: Yes
Switch layer: L3

Weight & dimensions
Depth: 327 mm
Height: 43.9 mm
Weight: 4.9 kg
Width: 442 mm

Network
Networking standards: IEEE 802.3af, IEEE 802.3az, IEEE 802.1v, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1ak, IEEE 802.1D, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3ad, IEEE 802.1s, IEEE 802.1ab, IEEE 802.1t, IEEE 802.1AX, IEEE 802.1w, IEEE 802.3at, IEEE 802.1Q, IEEE 802.3x
10G support: Yes
VLAN support: Yes
Flow control support: Yes
Number of VLANs: 4094
Spanning tree protocol: Yes
Link aggregation: Yes

Performance
Memory type: DDR4SDRAM
Internal memory: 8192 MB
Processor frequency: 1800 MHz
Builtin processor: Yes
Flash memory: 16384 MB
Processor model: ARM CortexA72
Physical stacking (units): 8

Protocols
Management protocols: SNMPv2c, SNMPv3
Routing protocols: RIP2, OSPFv2, OSPFv3

Ports & interfaces
Basic switching RJ45 Ethernet ports quantity: 24
SFP+ module slots quantity: 4
Basic switching RJ45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
USB TypeA ports quantity: 1
Console port: USB

Data transmission
Packet buffer memory: 8 MB
Switching capacity: 128 Gbit/s
MAC address table: 32768 entries
Throughput: 95.2 Mpps
Jumbo frames support: Yes
Latency (10 Gbps): 1.46 s
Latency (1 Gbps): 2.28 s

Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget: 370 W
Power over Ethernet (PoE): Yes

Multicast features
Multicast support: Yes
MLD entries: 1024

Optical fiber
Transmission distance (max): 10 km
