Tecnoware 550W ATX POWER SUPPLY ENCLOSURE FAL550FS12

Technical details
Compliance certificates: CE

Design
Cooling type: Active
Fan location: Top
Product colour: Black
On/off switch: Yes
Fan diameter: 12 cm

Power
Max output current (+5Vsb): 2.5 A
Max output current (+3.3V): 23 A
Power protection features: Short circuit, Over voltage, Overload
Input current: 5 A
Max output current (12V): 0.8 A
Max output current (+5V): 24 A
Efficiency: 86%
Max output current (+12V): 30 A
AC input voltage: 180 264 V
Total power: 550 W
AC input frequency: 47 63 Hz

Operational conditions
Operating temperature (TT): 0 40 C
Storage temperature (TT): 15 40 C
Operating relative humidity (HH): 0 90%

Weight & dimensions
Depth: 140 mm
Height: 85 mm
Weight: 1 kg
Width: 150 mm

Performance
Power supply unit (PSU) form factor: ATX
Safety: 2014/35/UE; EMC 2014/30/UE
Purpose: PC

Packaging data
Package type: Box

Ports & interfaces
Peripheral (Molex) power cable length: 500
ATX power connector (20+4 pin): Yes
EPS power connector (4+4 pin): Yes
Floppy disk drive connector: Yes
Floppy disk drive cable length: 65 cm
Motherboard power cable length: 35 cm
Motherboard power connector: 20+4 pin ATX
CPU power connector (4+4 pin): Yes
Floppy drive power connector: 1
Cabling type: NonModular
Peripheral (Molex) power connectors (4pin): 2
Number of SATA power connectors: 2
