Tp-link AC2100 Wireless MU-MIMO VDSL/ADSL Modem Router

Certification: CE, RCM, RoHS

Features
Firmware upgradeable: Yes

Design
On/off switch: Yes
Product type: Tabletop router
Product colour: Black
LED indicators: LAN, Power, Status, WLAN
Wall mountable: Yes

Power
Power source type: DC
Output voltage: 12 V
Output current: 1.5 A

Security
Security algorithms: 64bit WEP, WPA2, WPA2PSK, WPA, 128bit WEP, WPAPSK
Network address translation (NAT): Yes
Filtering: Yes
Access Control List (ACL): Yes
Firewall: Yes
Parental control: Yes
Guest access: Yes
DMZ support: Yes

Operational conditions
Operating relative humidity (HH): 10 90%
Storage relative humidity (HH): 5 90%
Storage temperature (TT): 40 70 C
Operating temperature (TT): 0 40 C

Management features
Webbased management: Yes
Reset button: Yes
WPS push button: Yes
MUMIMO technology: Yes

Weight & dimensions
Depth: 164 mm
Width: 216 mm
Height: 36.8 mm

Network
Ethernet LAN interface type: Gigabit Ethernet
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN: Yes
Ethernet LAN data rates: 1000 Mbit/s, 100, 10
Cabling technology: 10/100/1000BaseT(X)
VPN Passthrough: Yes
VPN tunnels quantity: 10
Dynamic DNS (DDNS): Yes
Static route: Yes
Port triggering: Yes
Port forwarding: Yes
USB sharing: Yes
Number of guest networks (5 GHz): 1
Number of guest networks (2.4 GHz): 1

System requirements
Linux operating systems supported: Yes
Windows operating systems supported: Windows 2000, Windows 8.1, Windows Vista, Windows 7, Windows XP, Windows 98SE, Windows 8, Windows 10
Mac compatibility: Yes
Mac operating systems supported: MacOS

Packaging data
Package height: 71 mm
Package width: 318 mm
Package weight: 1.17 kg
Package depth: 240 mm

Packaging content
Cables included: Phone (RJ11), LAN (RJ45)
AC adapter included: Yes
Quick installation guide: Yes

Wireless LAN features
WLAN data transfer rate (max): 1733 Mbit/s
WiFi standards: 802.11g, WiFi 5 (802.11ac), WiFi 4 (802.11n), 802.11a, 802.11b
Top WiFi standard: WiFi 5 (802.11ac)
WLAN data transfer rate (second band): 300 Mbit/s
WLAN data transfer rate (first band): 1733 Mbit/s
WiFi band: Dualband (2.4 GHz / 5 GHz)

Protocols
Supported network protocols: IPv4, IPv6
DHCP client: Yes
Universal Plug and Play (UPnP): Yes
DHCP server: Yes

Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 1
DCin jack: Yes
Ethernet LAN (RJ45) ports: 3
RJ11 ports quantity: 1
USB port: Yes
Memory card slot(s): No

Antenna
Antennas quantity: 4
Antenna design: Internal & external

WAN connection
Ethernet WAN: Yes
DSL WAN: Yes
WAN connection type: RJ45
3G/4G USB modem compatibility: Yes
SIM card slot: No

DSL features
ADSL2: Yes
VDSL2: Yes
ADSL2+: Yes
VDSL: Yes
ADSL: Yes
