Transcend Compact Flash 16GB 170x

Transcend Compact Flash 16 GB 170x

Transcend's Industrial CF170 CompactFlash cards are equipped with fast data transfer rates and a particularly large capacity, making them ideal for embedded systems, medical instruments, road surveillance systems and other industrial applications with high performance requirements. Thanks to the use of static data refresh and early retirement, CF170 CF cards are particularly errorprone, have high data integrity and an extended lifetime.

Advantages:

• RoHS compatible
• CompactFlash Version 6.0 suitable
• Supports S.M.A.R.T (user defined)
• Supports Security Command
• Supports static data refresh and early retirement to extend product life
• Operation mode: PCCard Memory, PCCard IO, True IDE
• True IDE Mode supported: UDMA05, MDMA02, PIO06
• True IDE mode: Hard disk (default)
• PC Card Mode supports up to Ultra DMA Mode 5
• PC Card Mode: Removable Disk (Standard)
• Builtin ECC (Error Correction Code) and WearLevelling Algorithm for reliable data transmission
• Power Shield prevents data loss in case of sudden power failure (optional function)

Features:

• Dimensions: 42.8 x 36.4 x 3.3 mm
• Pin: 50 pin
• Form factor: CF card
• Flash type: MLC NAND Flash
• Capacity: 16 GB
• Max. read speed: 87 MB/s
• Max. writing speed: 68 MB/s
