Intel Procesor Core i5-14500 2.6GHz LGA1700 Box, BX8071514500

Technical details
OpenCL version: 3.0
Launch date: Q1'24
Status: Launched

Processor
Processor boost frequency: 5 GHz
Processor model: i514500
Processor operating modes: 64bit
Processor cores: 14
Processor cache: 24 MB
Efficient cores: 8
Processor family: Intel Core i5
Processor codename: Raptor Lake
Processor manufacturer: Intel
Processor threads: 20
Performance cores: 6
Efficientcore boost frequency: 3.7 GHz
Bus type: DMI4
Processor socket: LGA 1700
Maximum number of DMI lanes: 8
Efficientcore base frequency: 1,9 GHz
Processor cache type: Smart Cache
Processor base power: 65 W
Performancecore base frequency: 2,6 GHz
Performancecore boost frequency: 5 GHz
Processor generation: Intel Core i5 14th generation
Box: Yes
Maximum turbo power: 154 W
Memory bandwidth supported by processor (max): 76.8 GB/s

Graphics
Onboard graphics card: Yes
Discrete graphics card: No
Onboard graphics card DirectX version: 12.0
Onboard graphics card model: Intel UHD Graphics 770
Discrete graphics card model: Not available
Onboard graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
Onboard graphics card refresh rate at maximum resolution (HDMI): 60 Hz
Onboard graphics card refresh rate at maximum resolution (eDP Integrated Flat Panel): 120 Hz
Onboard graphics card base frequency: 300 MHz
Number of execution units: 32
Onboard graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, HDMI 2.1, DisplayPort 1.4a
Onboard graphics card dynamic frequency (max): 1550 MHz
Number of displays supported (onboard graphics): 4
Onboard graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
Onboard graphics card maximum resolution (HDMI): 4096 x 2160 pixels
Onboard graphics card OpenGL version: 4.5
Onboard graphics card maximum resolution (eDP Integrated Flat Panel): 5120 x 3200 pixels

Features
PCI Express slots version: 5.0, 4.0
PCI Express configurations: 1x16+1x4, 2x8+1x4
CPU configuration (max): 1
Thermal Monitoring Technologies: Yes
Execute Disable Bit: Yes
Embedded options available: Yes
Use conditions: PC/Client/Tablet, Workstation
Idle States: Yes
Scalability: 1S
Maximum number of PCI Express lanes: 20
Supported instruction sets: SSE4.2, SSE4.1, AVX 2.0
Direct Media Interface (DMI) Revision: 4.0
Market segment: Desktop

Memory
Memory bandwidth (max): 76.8 GB/s
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR4SDRAM, DDR5SDRAM
Memory channels: Dualchannel

Operational conditions
Tjunction: 100 C

Weight & dimensions
Processor package size: 45 x 37.5 mm

Processor special features
Intel Volume Management Device (VMD): Yes
Intel Hyper Threading Technology (Intel HT Technology): Yes
Intel Active Management Technology (Intel AMT): Yes
Intel 64: Yes
Intel Secure Key: Yes
Intel Quick Sync Video Technology: Yes
Intel Boot Guard: Yes
Intel VTx with Extended Page Tables (EPT): Yes
Intel Trusted Execution Technology: Yes
Intel Stable Image Platform Program (SIPP): Yes
Intel Virtualization Technology for Directed I/O (VTd): Yes
Intel Virtualization Technology (VTx): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel vPro Essentials Platform Eligibility: Yes
Intel Clear Video HD Technology (Intel CVT HD): Yes
Intel AES New Instructions (Intel AESNI): Yes
Intel Deep Learning Boost (Intel DL Boost): Yes
Modebased Execute Control (MBE): Yes
Intel Turbo Boost Technology: 2.0
Intel Turbo Boost Max Technology 3.0: No
Intel Virtualization Technology with Redirect Protection (VTrp): Yes
Intel Speed Shift Technology: Yes
Intel Gaussian & Neural Accelerator (Intel GNA) 3.0: Yes
Intel OneClick Recovery: Yes
Intel OS Guard: Yes
Intel Standard Manageability (ISM): Yes
Intel Controlflow Enforcement Technology (CET): Yes
Intel Thread Director: Yes
Intel vPro Platform Eligibility: Yes
Intel Total Memory Encryption Multi Key: Yes
Intel Threat Detection Technology (TDT): Yes
Intel Remote Platform Erase (RPE): Yes
Intel vPro Enterprise Platform Eligibility: Yes
Intel Hardware Shield Eligibility: Yes

Other features
Maximum internal memory: 192 GB
Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1
