Zyxel XMG-105 5 Port 10/2.5G PoE++ Switch

Plugandplay to Upgrade Your Network to WiFi 6/6E/7
The XMG100 Series of 2.5G switches includes 5 and 8port models with or without PoE options. These switches are equipped with multigig ports supported up to 2.5G and can easily be connected to the latest 2.5G–capable network devices including WiFi 6/6E/7 APs, 5G CPE, 2.5G storage, 4K/8K TV, PC with 2.5G NIC and gaming consoles. This streamlined plugandplay technology enables highperformance networking and a smoother home entertainment or multimedia creation experience.

Extra 10G Port to Streamline Large File Transfers
The 10Gigabit SFP+ model increases the network speed for quicker uploads and downloads through a NAS and server, allowing content creators or selfmedia individuals to work more efficiently. Large files, such as highresolution videos or images, can be transferred in significantly less time, saving valuable production hours.

Single Cable for Both Power and Data
PoE models come with either 4 or 8 uninterrupted PoE++ (60W) ports and a budgetfriendly PoE budget of 70W or 100W – deploying PoE devices like WiFi 6/6E/7 APs, PTZ cameras and IoT devices has never been easier.

2.5G SuperFast Speeds Without Recabling
You can use your current Cat 5e cables to increase your home networking speed from 1Gbps to 2.5Gbps, eliminating the need for any costly recabling.

Silent Operation and Flexible Deployment
The XMG100 Series has a robust and fanless design for stable and silent operation, and is perfect for noisefree environments in the home or studio. Its compact design offers the flexibility to place the switch on a desktop or mount it on a wall.

Accelerate your Networking Experience
The XMG100 Series offers home or SOHO users who need lagfree and nonintermittent network services for their online gaming or multimedia streaming services, a faster, more secure connection.

Features:

• Product name: 5Port 2.5G PoE Unmanaged Switch with 10G Uplink
• Port Density:
  • Total port count: 6
  • 2.5G BASET: 5
  • 1G SFP/10G SFP+: 1
• PoE:
  • IEEE 802.3bt (PoE++, 60 W): 4
  • Total PoE budget (watts): 70
• Performance:
  • Switching capacity (Gbps): 45
  • Forwarding rate (Mpps): 33.5
  • Packet buffer (byte): 1 MB
  • MAC address table: 4 K
  • Jumbo frame (byte): 12 K
• Power:
  • Input: 100 240 V AC, 50/60 Hz
  • Power supply: External
  • Max. power consumption (watts): 90
  • Min. power consumption (watts): 1.62
• Physical Specifications:
  • Dimensions (WxDxH) (mm / in.): 160 x 110 x 26 / 6.30 x 4.33 x 1.02
  • Weight (kg / lb.): 0.492 / 1.09
• Fanless: Yes
