MSI MPG A1000G PCIE5 power supply unit 1000 W 20+4 pin ATX ATX Black
Design Product colour: Black Fan diameter: 13.5 cm Number of fans: 1 fan(s) Cooling type: Active Illumination: No Power Power protection features: Overheating, Short circuit, Over voltage, Over power, Under voltage, Over current AC input frequency: 50 60 Hz Max output current (+5Vsb): 3 A Max output current (+5V): 22 A Max output current (+12V): 83.5 A Combined power (+3.3V): 120 W Power Factor Correction (PFC) type: Active AC input voltage: 100 240 V Combined power (+5V): 120 W Max output curr
Brend:MSI
- Na zalihama
- Na zalihama

MSI MPG A1000G PCIE5 power supply unit 1000 W 20+4 pin ATX ATX Black
Trenutno najbolja ponuda:
203,50 €u Tia mobiteli
Slični proizvodi iz Napajanja
Opis i karakteristike
Design
Product colour: Black
Fan diameter: 13.5 cm
Number of fans: 1 fan(s)
Cooling type: Active
Illumination: No
Power
Power protection features: Overheating, Short circuit, Over voltage, Over power, Under voltage, Over current
AC input frequency: 50 60 Hz
Max output current (+5Vsb): 3 A
Max output current (+5V): 22 A
Max output current (+12V): 83.5 A
Combined power (+3.3V): 120 W
Power Factor Correction (PFC) type: Active
AC input voltage: 100 240 V
Combined power (+5V): 120 W
Max output current (+3.3V): 22 A
Efficiency: 90%
Max output current (12V): 0.3 A
Total power: 1000 W
Combined power (+5Vsb): 15 W
Combined power (12V): 3.6 W
Combined power (+12V): 1000 W
Weight & dimensions
Depth: 150 mm
Height: 86 mm
Width: 150 mm
Performance
Bearing technology: FDB
Purpose: PC/Server
80 PLUS certification: 80 PLUS Gold
Power supply unit (PSU) form factor: ATX
ATX version: 3.0
Ports & interfaces
Number of SATA power connectors: 12
Cabling type: FullyModular
Peripheral (Molex) power cable length: 500, 1100, 700, 850 mm, 650
Motherboard power cable length: 60 cm
Floppy disk drive connector: Yes
EPS power connector (8pin): No
Peripheral (Molex) power connectors (4pin): 4
EPS power connector (4+4 pin): Yes
PCI Express power connectors (6+2 pin): 6
SATA power cable length: 500, 700 mm, 850, 650 mm
Motherboard power connector: 20+4 pin ATX
PCI Express power cable length: 75 cm
PCI Express power connectors (16pin): 1
Other features
EPS cable length: 70 cm
Product colour: Black
Fan diameter: 13.5 cm
Number of fans: 1 fan(s)
Cooling type: Active
Illumination: No
Power
Power protection features: Overheating, Short circuit, Over voltage, Over power, Under voltage, Over current
AC input frequency: 50 60 Hz
Max output current (+5Vsb): 3 A
Max output current (+5V): 22 A
Max output current (+12V): 83.5 A
Combined power (+3.3V): 120 W
Power Factor Correction (PFC) type: Active
AC input voltage: 100 240 V
Combined power (+5V): 120 W
Max output current (+3.3V): 22 A
Efficiency: 90%
Max output current (12V): 0.3 A
Total power: 1000 W
Combined power (+5Vsb): 15 W
Combined power (12V): 3.6 W
Combined power (+12V): 1000 W
Weight & dimensions
Depth: 150 mm
Height: 86 mm
Width: 150 mm
Performance
Bearing technology: FDB
Purpose: PC/Server
80 PLUS certification: 80 PLUS Gold
Power supply unit (PSU) form factor: ATX
ATX version: 3.0
Ports & interfaces
Number of SATA power connectors: 12
Cabling type: FullyModular
Peripheral (Molex) power cable length: 500, 1100, 700, 850 mm, 650
Motherboard power cable length: 60 cm
Floppy disk drive connector: Yes
EPS power connector (8pin): No
Peripheral (Molex) power connectors (4pin): 4
EPS power connector (4+4 pin): Yes
PCI Express power connectors (6+2 pin): 6
SATA power cable length: 500, 700 mm, 850, 650 mm
Motherboard power connector: 20+4 pin ATX
PCI Express power cable length: 75 cm
PCI Express power connectors (16pin): 1
Other features
EPS cable length: 70 cm
