Aten 2-Port VGA Video Switch

Features
Supported graphics resolutions: 1600 x 1200 (UXGA), 640 x 480 (VGA), 1920 x 1440, 1024 x 768 (XGA), 800 x 600 (SVGA)
Output impedance: 75
Material: Plastic, Metal
LED indicators: Yes
Maximum operating distance: 10 m
Product colour: Silver
Input impedance: 75
Maximum refresh rate: 60 Hz
Maximum resolution: 1920 x 1440 pixels
Bandwidth: 150 MHz

Power
Power consumption (typical): 0.82 W

Operational conditions
Storage temperature (TT): 20 60 C
Operating relative humidity (HH): 0 80%
Storage relative humidity (HH): 0 80%
Operating temperature (TT): 0 50 C

Weight & dimensions
Weight: 220 g
Height: 44 mm
Width: 65.2 mm
Depth: 120 mm

Packaging data
Package depth: 239 mm
Package weight: 360 g
Package width: 59 mm
Package height: 160 mm

Packaging content
Quantity per pack: 1 pc(s)
AC adapter included: Yes

Ports & interfaces
VGA (DSub) ports quantity: 3
VGA (DSub) input ports: 2
VGA (DSub) output ports: 1
DCin jack: Yes
Video port type: VGA

Logistics data
Master (outer) case height: 338 mm
Master (outer) case net weight: 4.4 kg
Master (outer) case length: 490 mm
Master (outer) case gross weight: 7.9 kg
Harmonized System (HS) code: 85176990
Master (outer) case width: 315 mm
Products per master (outer) case: 20 pc(s)
