Asus 1700 AS PRIME B760M-K D4

Processor
Compatible processor series: Intel Core i7, Intel Core i9, Intel Pentium Gold, Intel Core i5, Intel Celeron, Intel Core i3
Processor manufacturer: Intel
Supported processor sockets: LGA 1700
Processor socket: LGA 1700

Graphics
Parallel processing technology support: Not supported

Features
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 10 x64, Windows 11
Motherboard chipset: Intel B760
Motherboard form factor: micro ATX
Motherboard chipset family: Intel

Memory
Supported memory clock speeds: 2400, 2800, 5066 MHz, 4000, 4800, 3200, 2666, 4266, 2133, 3466, 3733, 4400, 5000, 3400, 4600 MHz, 3000, 5333 MHz, 2933, 3600, 3333
Maximum internal memory: 64 GB
Number of memory slots: 2
Memory channels: Dualchannel
Supported memory types: DDR4SDRAM
Unbuffered memory: Yes
Memory slots type: DIMM
Supported memory clock speed (max): 5333 MHz

Weight & dimensions
Height: 36 mm
Depth: 211 mm
Width: 244 mm

Network
WiFi: No
Ethernet interface type: 2.5 Gigabit Ethernet
WakeonLAN ready: Yes
Ethernet LAN: Yes

Internal I/O
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
EPS power connector (8pin): Yes
Front panel audio connector: Yes
12V power connector: Yes
Number of chassis fan connectors: 1
RGB LED pin header: Yes
ATX Power connector (24pin): Yes
USB 2.0 connectors: 2
S/PDIF out connector: Yes
TPM connector: Yes
Number of SATA III connectors: 4
Number of COM connectors: 1

BIOS
BIOS type: UEFI AMI

Packaging data
Package depth: 51.5 mm
Package weight: 926.3 g
Package height: 263 mm
Package width: 270 mm

Packaging content
Cables included: SATA

Storage controllers
RAID levels: 1, 0, 10, 5
Number of storage drives supported: 6
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
Number of HDDs supported: 4

Rear panel I/O ports
Microphone in: Yes
HDMI ports quantity: 1
PS/2 ports quantity: 1
VGA (DSub) ports quantity: 1
USB 2.0 ports quantity: 2
USB connector type: USB TypeA
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 4
Ethernet LAN (RJ45) ports: 1

Expansion slots
Number of M.2 (M) slots: 2
PCI Express x1 (Gen 4.x) slots: 2
PCI Express x16 (Gen 4.x) slots: 1

Other features
Weight: 528 g
