Asus AM5 AS TUF GAMING X870-PLUS WIFI

Processor
Compatible processor series: AMD Ryzen 7 7th Gen, AMD Ryzen 9 9th Gen, AMD Ryzen 9 7th Gen, AMD Ryzen 7 8th Gen, AMD Ryzen 9 8th Gen
Processor socket: Socket AM5
Processor manufacturer: AMD

Graphics
Parallel processing technology support: Not supported
Onboard graphics card: No

Features
Windows operating systems supported: Windows 11
Audio chip: Realtek ALC1220P
Motherboard chipset family: AMD
Product colour: Black
Audio output channels: 7.1 channels
Motherboard chipset: AMD X870
Motherboard form factor: ATX

Memory
Memory slots type: DIMM
Supported memory clock speed (max): 8000 MHz
Unbuffered memory: Yes
Number of memory slots: 4
Supported memory types: DDR5SDRAM
Maximum internal memory: 192 GB
Memory channels: Dualchannel

Weight & dimensions
Width: 305 mm
Depth: 244 mm

Network
Ethernet interface type: Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet
Ethernet LAN: Yes
WiFi: Yes
Bluetooth: Yes
Top WiFi standard: WiFi 7 (802.11be)
WiFi standards: WiFi 7 (802.11be)
Bluetooth version: 5.4

Internal I/O
Number of SATA III connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
CPU fan connector: Yes
USB 2.0 connectors: 2
Front panel audio connector: Yes
Number of COM connectors: 1
12V power connector: Yes
Number of chassis fan connectors: 4
EPS power connector (8pin): Yes
ATX Power connector (24pin): Yes
USB 3.2 Gen 2x2 connectors: 1

BIOS
BIOS type: UEFI AMI

Storage controllers
Supported storage drive types: HDD & SSD
RAID levels: 10, 1, 5, 0
Number of HDDs supported: 2
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Number of storage drives supported: 6

Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 3
USB 2.0 ports quantity: 1
USB4 Gen 3x2 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 4
USB connector type: USB TypeA, USB TypeC
Ethernet LAN (RJ45) ports: 1
Microphone in: Yes
HDMI ports quantity: 1

Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 4
