Asus PRIME A620M-A-CSM AMD A620 Socket AM5 micro ATX

Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 9 7th Gen, AMD Ryzen 7 7th Gen
Processor manufacturer: AMD
Processor socket: Socket AM5

Graphics
Parallel processing technology support: Not supported

Features
Motherboard chipset: AMD A620
Audio output channels: 7.1 channels
Motherboard form factor: micro ATX
Motherboard chipset family: AMD
Windows operating systems supported: Windows 11, Windows 10 x64

Memory
Supported memory clock speeds: 4800, 6000, 5200, 6200, 6400, 5600, 5000, 5800, 5400 MHz
Maximum internal memory: 128 GB
Unbuffered memory: Yes
Memory channels: Dualchannel
Supported memory clock speed (max): 6400 MHz
Number of memory slots: 4
Memory slots type: DIMM
Supported memory types: DDR5SDRAM

Weight & dimensions
Depth: 244 mm
Width: 244 mm
Height: 43 mm

Network
Ethernet LAN: Yes
WiFi: No
Ethernet interface type: Gigabit Ethernet

Internal I/O
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
S/PDIF out connector: Yes
USB 2.0 connectors: 2
Number of chassis fan connectors: 2
Front panel connector: Yes
TPM connector: Yes
CPU fan connector: Yes
EPS power connector (8pin): Yes
ATX Power connector (24pin): Yes
Number of COM connectors: 1
Front panel audio connector: Yes
RGB LED pin header: Yes
12V power connector: Yes

BIOS
BIOS type: UEFI AMI

Packaging data
Package height: 67.5 mm
Package width: 275 mm
Package depth: 275 mm
Package weight: 1.36 kg

Packaging content
Cables included: SATA

Storage controllers
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Number of storage drives supported: 6
RAID levels: 1, 0, 10
Number of HDDs supported: 4

Rear panel I/O ports
DisplayPorts quantity: 1
VGA (DSub) ports quantity: 1
Headphone outputs: 1
HDMI ports quantity: 1
PS/2 ports quantity: 1
Microphone in: Yes
Ethernet LAN (RJ45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 2
USB 2.0 ports quantity: 4
Linein: Yes

Expansion slots
PCI Express x1 (Gen 3.x) slots: 2
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 1
