Asus Matična ploča PRIME B650M-K AM5 1xVGA 1xHDMI

152,10 €
Tia mobiteli
Processor Supported processor sockets: Socket AM5 Compatible processor series: AMD Ryzen 9 7th Gen, AMD Ryzen 5, AMD Ryzen 7 Processor manufacturer: AMD Processor socket: Socket AM5 Graphics Parallel processing technology support: Not supported Features Motherboard form factor: micro ATX Windows operating systems supported: Windows 11, Windows 10 x64 Audio output channels: 7.1 channels Motherboard chipset family: AMD Motherboard chipset: AMD B650 Memory Unbuffered memory: Yes Supported memory c
Brend:Asus

Asus Matična ploča PRIME B650M-K AM5 1xVGA 1xHDMI

Trenutno najbolja ponuda:

152,10 €u Tia mobiteli

Opis i karakteristike

Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 9 7th Gen, AMD Ryzen 5, AMD Ryzen 7
Processor manufacturer: AMD
Processor socket: Socket AM5

Graphics
Parallel processing technology support: Not supported

Features
Motherboard form factor: micro ATX
Windows operating systems supported: Windows 11, Windows 10 x64
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Motherboard chipset: AMD B650

Memory
Unbuffered memory: Yes
Supported memory clock speeds: 6400, 5600, 5200, 5800, 5400 MHz, 5000, 6200, 4800, 6000
Maximum internal memory: 96 GB
Supported memory types: DDR5SDRAM
Memory slots type: DIMM
Number of memory slots: 2
Memory channels: Dualchannel
Supported memory clock speed (max): 6400 MHz

Weight & dimensions
Depth: 221 mm
Width: 244 mm

Network
WiFi: No
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet

Internal I/O
ATX Power connector (24pin): Yes
S/PDIF out connector: Yes
EPS power connector (8pin): Yes
Front panel audio connector: Yes
USB 2.0 connectors: 2
Number of SATA III connectors: 4
Number of COM connectors: 1
Number of chassis fan connectors: 2
TPM connector: Yes
CPU fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Audio connector: Yes
RGB LED pin header: Yes
12V power connector: Yes

BIOS
BIOS type: UEFI AMI

Packaging data
Package height: 51.5 mm
Package weight: 1.07 kg
Package depth: 270 mm
Package width: 260 mm

Packaging content
Cables included: SATA

Storage controllers
RAID levels: 1, 10, 0
Supported storage drive interfaces: M.2, SATA III
Supported storage drive types: HDD & SSD
Number of storage drives supported: 6
RAID support: Yes
Number of HDDs supported: 4

Rear panel I/O ports
USB 3.2 Gen 2 (3.1 Gen 2) TypeA ports quantity: 2
USB 2.0 ports quantity: 4
Ethernet LAN (RJ45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) TypeA ports quantity: 2
Microphone in: Yes
Linein: Yes
HDMI ports quantity: 1
Headphone outputs: 1
PS/2 ports quantity: 1
VGA (DSub) ports quantity: 1

Expansion slots
Number of M.2 (M) slots: 2
PCI Express x16 (Gen 4.x) slots: 2
PCI Express x1 (Gen 4.x) slots: 2
MBO AM5 AS PRIME B650M-K
Procesor
Socket
AMD AM5
Proizvođač procesora
AMD
Kompatibilni procesori
2nd Generation AMD Ryzen™ 3, 3rd Generation AMD Ryzen™ 3, 2nd Generation AMD Ryzen™ 5, 3rd Generation AMD Ryzen 5, 2nd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 9
Maksimalan broj SMP procesora
Memorija
Tip memorije
DDR5, DDR4
Broj memorijskih utora
4
Tip memorijskih utora
DIMM
Memorijski kanali
Dvokanalni
Maksimalna količina interne memorije (GB)
128
Memorija bez međuspremnika
Grafika
Maksimalna razlučivost (pikseli)
4096 x 2160
Podrška za tehnologiju paralelne obrade
2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX
Mreža
Wi-Fi
N
Karakteristike
Brend
Značajke
Chipset
AMD B650
Format ploče
Micro ATX
Kontroler uređaja za pohranu podataka
Podržana sučelja pogona za pohranu
SATA III
RAID tipovi
0, 1, 10
Interni I/O
USB 2.0 priključci
2
Broj SATA II priključaka
8
Audio priključak na prednjoj strani
ATX priključak napajanja (24-pin)
Priključak ventilatora za procesor
Broj priključaka za ventilatore na kućištu
2
TPM priključak
Broj EATX strujnih priključaka
Poveznik prednje ploče
Poveznik 12V napajanja
RGB LED pin header
